Ionizer Output Nozzle Tips

  • Change airflow of ionizers with output nozzles tips
  • 15° Angle
  • Wide Angle
  • Luer Lock
  • Long Range
  • Bendable
  • Manifold
Quantity:
Categories: , ,

Product Description

Change airflow of ionizers with output tips to handle unique and difficult point-of-use ionization applications.

The IN0010 nozzle tip comes standard with models: IN6430, IN3425, IN3425PE, IN4000, and IN4000PE . Wide angle, long range, bendable, luer lock or manifold tips may be substituted depending on the application.

Output Nozzle Tip Options:

N0010: Standard 15°
N0020: Wide Angle
N0030: Luer Lock
N0040: Long Range
N0050: Bendable
N0060: Manifold

Nozzle Options
