WP8200 ESD Inspection Wiper
WP8200 ESD Wiper

WP8200 – Cleanroom Safe ESD Inspection Wiper – 9″x9″

Buy Now

Item #: WP8200

  • Black Anti-Static Cleanroom Wipers are perfect for the cleaning and final inspection of sensitive components in controlled environments.
  • Visually inspecting the wipe is the quickest and easiest way to check cleanliness.  The black color  shows contamination.
  • Ideal for wiping exterior areas of products in ESD-sensitive areas as well as cleaning of process tools and other equipment.
  • Made out of 100% continuous polyester filaments with conductive carbon yarns (97% Polyester, 3% Carbon)
  • Good solvent resistance. Lint and particle free.
  • Static dissipative on both sides, unlike similar wipers that are dissipative on only one side.
  • Cleanroom Class Compatibility: Class 100 – Class 1000
  • Size: 9” x 9” (22.86cm x 22.86cm)
  • 150 Wipers Per Bag
Quantity:

Description

The WP8200 Black Anti-Static Cleanroom Wipers are ideal for cleaning and final inspection of sensitive components in controlled environments. Cleanroom safe ESD wipers are the perfect cleaning choice for materials at risk for damage from static.

WP8200 ESD Wipers are constructed with 100% continuous filament, no-run knit polyester with laser sealed cut edges. These cleanroom-safe black wipes have been developed to clearly and visibly show small particulate contamination. Their properties make them useful for both the final wipe down and for the final inspection of any surface in a critical environment or anywhere particles compromise quality or performance.

Applications:
WP8200 wipers are ideal for wiping critical surfaces to verify cleanliness. They  can be used in various industries such as semiconductor, optical, medical, cosmetics, food & beverage, printed circuit boards, building maintenance, automobile, air craft, LCD, magnetic tapes, oil, tools, equipment, glass, optics, etc.

WP8200 ESD Wiper Close Up

Why Use Black Wipers?

The purpose of wiping a surface with a cleanroom wipe is to remove contaminants including dust, dirt, oil, greases, soot, and flux. But, after wiping, how clean is the surface? How can an operator or quality inspector be sure?

Visually inspecting the wipe is the quickest and easiest way to check cleanliness. If the wipe looks dirty and the substrate looks clean, the wiping process was successful. That works well if the wipe and the contaminants are contrasting colors. Since most wipes are white, black or dark color soils are easily seen. However, many contaminants are not dark colored. Instead they are white or light colored. Since they are the same color as the wipe, visually inspecting the used wipe is not completely useful. This is especially true if the contaminant is particulate; especially small particulates.

WP8200 ESD Wiper

ESD Properties

Typical Surface Resistivity for the WP8200 wipers is 10^7— 10 ^8. Unlike wipers utilizing grids or stripes of conductive yarns, our ESD Black wipe is uniformly dissipative across its entire surface eliminating potential “hot spots” of charge or the need to contact to a specific grid for electrical discharge.

WP8200 ESD Wiper

Cleanroom Properties

The WP8200 ESD Wipers are compatible with class 100-1000 cleanrooms (ISO4  – ISO6). Laser sealed edges ensure ultra -low lint and contamination and they are double bagged and vacuum packaged in cleanroom packaging.

The WP8200 is ideal for wiping exterior areas of products in Cleanrooms and ESD-sensitive areas as well as cleaning of process tools and other equipment.  ESD wipers are used in many industries such as semiconductor, optical, medical, cosmetics, food & beverage, printed circuit boards, building maintenance, automobile, aircraft, LCD, magnetic tapes, oil, tools, equipment, glass, optics, etc.

Features

  • Static Dissipative Wipers for General Cleaning and Inspection Applications
  • Suitable for Class 100 -1000 Cleanrooms (ISO 4—ISO 6)
  • 100% Continuous Polyester Filament with Conductive Carbon Yarn (97% Polyester, 3% Carbon)
  • ESD Resistivity: 10^7 – 10^8 ohms/sq
  • Good Solvent Resistance
  • Lint and Particle Free
  • Inspection Wipe: Black Color Shows Contamination To Ensure Cleanliness

Specification

  • Fabric: Polyester and Conductive Carbon
  • Size: 9″x9″
  • Basis Weight: 140 gsm
  • Thickness: 0.48-0.56mm
  • Absorptive Capacity: 300 ml/m^2
  • Absorptive Rate: 1.0 sec

Packaging

  • Packaged 150 wipers to a pack, vacuum sealed and double bagged
  • 10 Packs to a Case (1500 Wipers)

Additional information

Weight 2 lbs
Dimensions 9 × 9 × 4 in
Type

ESD Black Cleanroom Wipers

Size

9” x 9” (22.86cm x 22.86cm)

Color

Black

Pack Size

150 Wipers to a Pack, 10 packs to a Case (1500)

Tribo-charge

Less than 100 volts

Cleanroom Class

Class 100 – Class 1000

Particulate Release

Low

Saturation:

Dry
