BFN801 Benchtop Ionizing Blower

Item #: BFN801

  • Excellent static elimination performance
  • Coverage Range: 1’ x 5’ area
  • Uses AC technology to produce a balanced output of air ions:+10 volt
  • Built-in emitter point cleaner
  • Variable fan speed control
  • Easy to clean and safe to access
  • Removable finger guards with auto shut-off sensor
    • 0 $
Quantity:

Description

The BFN801 provides excellent balance and rapid charge decay for secure ESD workstation protection.

The BFN 801 benchtop ionizing blower, with inherently stable AC technology, provides excellent balance and rapid charge decay for secure workstation protection. Designed to protect most sensitive electronic devices, the BFN 801 uses corona ionizing technology to continuously produce a balanced output of positive and negative air ions.

Performance and Design Excellence
BFN series AC ionizers from Transforming Technologies create a dense and well-balanced ionization current. They are unique in their ability to deliver fast decay times with low offset voltages. Continuous balance and decay protection is assured by the reliable AC design.

Built with the User in Mind
An integrated emitter point cleaner, removable front and rear fan guards, safety switch combine to make the BFN 801 a user-friendly ionizer. The safety switches turn off all power to the ionizer during service for the operator safety.

Applications
The BFN801 designed to neutralize electrostatic charges in bench top environments, sensitive materials assembly, Medical Device, SMT, Electronics Assembly, Automotive packaging, clean room and laboratory environments.

Verification and Calibration:
The BFN801 ionizer comes factory calibrated and with a calibration certificate.  Ionizer performance can be tested and verified with a charge plate monitor. Important tests to perform are positive and negative decay times and ion balance. It is recommended to test ionizer performance at least 1 per year.

Additional information

Weight 10 lbs
Dimensions 13 × 10 × 7 in
Coverage

1ft. x 5ft. area

Decay

Less Than 2secs at 12in.

Balance

0 +10 volts

Power Input

120V AC

Finsh

Powder coat, gray

Enclosure

Steel

Approvals

CE

Audible Noise

44dB(A) (Distance 1 meter)

Temperature

32-122° F (0-50° C)

Warranty

1 Year (Manufacturer Defects)

Ozone Production

< 0.003 ppm, 12” in

RH Operating Range

20-60%, non-condensing

Troubleshooting

Follow this link to our Troubleshooting Guide for the BFN Series Ionizers:

bfn-ionizers-trouble-shoot-video

How To Clean Ionizers

Cleaning BFN Ionizers

Download BFN Cleaning Guide

Cleaning your ESD ionizers is a very important maintenance step.  Ionizers can experience performance issues when they are dirty, that can be solved with a simple cleaning. Emitter points can become dirty over time which slows decay times.  The body of the ionizer can collect dust, specifically inside and around the fan, which can high voltage arcing or full failures.

Emitter Point Cleaning: Integrated Brush

  • Turn brush clockwise & counter-clockwise several times
  • Do not turn the brush 360 degrees. There is a stopping point at the bottom left
  • Periodically, use Isopropyl Alchohol with a  clean cloth to clean emitter points

Internal Fan Clean

  • Remove fan guards
  • Use clean dry compressed air to remove any dust or particles
  • Use Isopropyl Alchohol with a  clean cloth to clean fan assembly

Considerations

  • Make sure the ionizer is unplugged before cleaning
  • Isopropyl Alcohol can be diluted with distilled water
  • Acetone is not necessary
  • Emitter points should be completely dry before operation.
